Commissioning Messages and Warnings
46 BUG 3/2/20 Basic Feed Unit
5.96064.02 Baumüller Nürnberg GmbH
6.2 Messages and Warnings
On the front panel of the Basic Feed Unit, there are six LEDs that indicate the messages listed below.
These messages are stored and you can reset them by either switching on again or by a Reset on
terminal strip X1 (contacts 1,2).
Possible messages:
System error
Ready-for-Use
Intermediate Circuit
Ballast
Controller Supply
Temperature
• Ready-for-Use
If no message is pending, the green ready-for-use LED is lit and the system reports this condition
to the servo units. If only one message of the BUS servo units is pending and the group message
on the servo units is activated in the BEDAS, the system cancels ready-for-use and does not indi-
cate any further messages.
• Intermediate Circuit
If the intermediate circuit voltage exceeds the set limit value, the system issues a message and
displays it. Ready-for-use is cancelled.
This message is issued in the following cases:
− braking energy is greater than P
maxBallast
− ballast circuit is missing
− wrong or defective external ballast resistor
