Baxi ECO3 COMPACT - Gas Valve (HONEYWELL)

Documento riservato – A solo uso interno / Confidential document – Internal use only
HONEYWELL
VK 4105 M
P. min
P. max
Inlet gas
pressure
Burner gas
pressure
MODULATOR ELECTRIC FEATURES :
- Modulating Coil Ohmic Resistance: 40 Ohm (T=25°C)
- Voltage to the Modulator: max 9 V dc (N.G.)
max 13 V dc (LPG)
- Electric Current with Natural Gas: 30 - 230 mA dc
- Electric Current with L.P.G.: 45 - 310 mA dc
GAS VALVE
ELECTRIC SUPPLY: 230 Vrac
(rectified)
(Electric coils connected in parallel)
Max.supply gas pressure: 60 mbar
Code: 5665220
GAS VALVE for open flue and fanned flue
