Baxtran STI - Page 30

ENUSER MANUAL STI
30
Error Message Description QTY Spec
1 Pan 1
2 Top cover 1
3 “+”screw 5 M4x8
4 Battery cover 1
5 Level bubble 14.7 1
6 Acrylic board 1
7 Overlay 1
8 Front display board 1
9 Printer fixed bracket 1
10 Printer paper cutter 1
11 TP230 printer module 1
12 Printer cover 1
13 Printer cover 1
14 TP230 printer axis 1
15 “+” round self thread screw 9 ST4x12
16 Printer button 1
17 Spring 2
18 Paper baffel 1
19 TP230 printer control board 1
20 Paper axis 1
21 Roll paper 1
22 Load cell bracket rubber 4
23 Internal hexagon screw 4 M6x20
24 Spring washer 4 M6
25
Washer 4 M6
26
Load cell bracket 1
27
Load cell 1
28
Hexagon screw 4 M4x16
29
Hexagon nut 4 M4
30
“+” round self thread screw 4 ST4x20
31
Load cell bracket 1
32
6V10Ah lead acid battery 1
33
“+” round self thread screw 4 ST4x8
34
Cable gland 4
35
Calibration switch board 1
36
Interface board 1
37
“+” round self thread screw 9 ST3x8
38
Round adaptor jack 1
39
Bottom cover 1
40
Fixed foot 4
41
Foot 4
42
Seal plastic 2
43
Fragile paper 2
