185, 195, 205, & 225 • Owner’s Manual
Supplement
Chapter 7: Deck Equipment
59
Convertible Top (If Equipped)
1. Unzip, remove, and stow the storage boot.
2. Insert the balls of the main bow (A) into the sockets on the windshield frame and secure them with the pins.
3. Insert the end eyes of the aft braces (B) into the deck hinges and secure them with the pins.
4. Unfold the canvas top and snap the front edge of the top (C) to the windshield frame.
5. Align the secondary bow (D) with the center seam of the canvas by loosening or tightening the top straps.
• The jaw slides (E) should not need to be adjusted.
• If you decide to adjust the jaw slide position, get the correct measurements from your selling dealer.
C
B
E
D
A
END EYE
DECK
HINGE
SECURING
PIN
SECURING PIN
SOCKET
BALL
