Chapter 7: Deck Equipment 185, 195, 205, & 225 • Owner’s Manual Supplement
60
Side Curtains (205 & 225 Only) (If Equipped)
1. Snap the forward corner
(A) of the side curtain
to the windshield frame.
2. Working your way aft,
alternately snap the top
snaps to the canvas top
and the bottom snaps to
the windshield frame
and deck.
3. Insert the side curtain
stud (B) into the socket
on the canvas top.
B
A
