Chapter 2: Locations 265 • Owner’s Manual Supplement
22
Marine Head Seawater Intake Seacock:
• Located under the bottom entry step.
• Access by lifting up the bottom entry step.
Power Trim and Tilt Pump & Reservoir
• Located in the port aft corner of the
engine room.
Shore Power Inlet(s):
• Located inside the transom storage locker.
BOTTOM
ENTRY STEP
POWER TRIM & TILT PUMP & RESERVOIR
A
F
T
SHORE POWER
INLET(S)
