Bayliner 265 - Spotlight Control Panel and Trim Tab Pump; Waste Holding Tank and Pump-Out Fitting

Chapter 2: Locations 265 • Owner’s Manual Supplement
24
Spotlight Control Panel
(If Equipped):
• Located at the helm.
Trim Tab Pump & Reservoir
• Located on the port aft wall
of the engine room.
Waste Holding Tank:
• Located on the starboard side
of the engine room.
SPOTLIGHT CONTROL
PANEL (IF EQUIPPED)
TRIM TAB PUMP
AFT
& RESERVOIR
WASTE TANK
