CTI 1 Manual V2 Aug 11
6
Technical Specification
Power Requirements 9-12Vdc 500mA
Inputs BBV RS422 or Pelco P 2 Wire RS485 or 2 Wire RS422 Simplex via
5 pin Green Screw Terminal Connector
Maximum Cable Distance Belden 8723 = 1200mtrs
Outputs 1 x BBV Coax Telemetry via BNC Connectors
Minimum Cable distance = 5mtrs
Maximum Cable Distance RG59 = 250mtrs
CT125 = 500mtrs
Facilities Supports 8 addresses
LED as power & address valid data
LED Coax telemetry active
TEST SWITCH sends a command to the
camera or receiver.
Boxed Dimensions. Length 69mm
Width 57mm
Height 36mm
Weight 64 grams
CTI/1 Software Version History
Version 1 December 2008
1. CTI/1 Released
Support of BBV, Pelco P RS485 input protocols converting to BBV Coax output protocol
Version 5 August 2011 1. Added test button function.
When the push button is pressed the CTI1 outputs pan right speed 7 command and stop on release.
