17
Moving the Trigger
The Float 32 allows you to install the trigger in the left or right shoulder strap, depending on your
preference. This feature is not available in the Float 22 or Float Throttle.
Removing
1. Open the zipper on the shoulder strap containing the trigger.
2. Untighten the small screw that attaches the trigger to the webbing loop inside the shoulder strap.
3. Pull the trigger and cable out (a) through the shoulder strap zipper.
a
Installing
1. Starting at the shoulder strap zipper (a), thread the trigger cable, leading with the trigger cover,
back into the pack (b). Be sure the trigger cable is fed underneath the airbag components.
2. Feed trigger cable through the opening in bottom right corner of the airbag compartment (c) into
the main storage pocket that stores the cylinder.
3. Inside the shoulder strap zipper, secure the trigger cable by fastening the screw on the trigger
assembly to the webbing loop.
a
b
b
c
Installing / Maintenance and Storage
