BCP SKY4719 - Charging Dock Setup; Charging Dock Component Identification

SETTING UP CHARGING DOCK
H
POWER INDICATOR
POWER
ADAPTER JACK
SIGNAL EMISSION WINDOW
POSITIVE
RECHARGING POLE
NEGATIVE
RECHARGING POLE
NOTE: Robot vacuum unit can also be charged with the power adaptor by plugging directly into the unit.
