BCP SKY6604 - Page 10

10 |
U-STAND ASSEMBLY
1
Connect the two part A upper frame bars with one part 1 screw, then set aside.
2
Connect the two part B lower frame bars with by attaching them to the part C lower frame bar
connector with two part 1 screw, then set aside.
1
1
x2
A
A
B
B
C
