| 11
U-STAND ASSEMBLY
3
Attach two part E legs to the part B lower frame assembly with two part 2 plastic washers and
two part 1 screws. Place the R on your right and the L on your left.
NOTE: When attaching the bars to the legs, make sure the notches in the mounting holes are
pointing downward.
Attach two part A upper frame bars to the part E legs with two part 2 plastic washers and two
part 1 screws.
4
Attach two part D support braces to the part B lower frame bars with two part 1 screws, then
attach to the part A upper frame bars with two more part 1 screws.
L
R
D
D
R
L
R
E
E
2
x4
1
x4
1
x4
To Next Page
