BCP SKY6604 - Page 12

12 |
U-STAND ASSEMBLY
5
Attach one part 4 large slider sticker to each end of the part E legs, four stickers total.
Attach one part 5 small slider sticker to the round recesses on the part A upper frame bars, two
stickers total.
Attach two part 6 square slider stickers to the square recesses on the bottom of the part B
bottom frame bars.
NOTE: Peel the white covering o the stickers before attaching.
6
Insert two part 3 mounting knobs into the part F mounting straps, then attach the straps to
each of the part A upper frame bars with one part 1 screw each.
NOTE: Insert the screw in the single round hole on one end of the strap, and the knob into the
square holes.
L
R
L
R
F
F
5
x2
6
x2
4
x4
1
x2
3
x2
