BCS 630 - Machine Maintenance

BCS Crusader Power Scythes
Page 18 CPS/MAX/0617
Maintenance Guide
MACHINE MAINTENANCE
For detailed engine maintenance please refer to engine manufacturers manual.
After every hour of operation stop the engine and remove the spark plug cap. Check engine oil
level (recommended oil SAE 10w/40).
Before checking the oil level ensure the machine is level.
Remove the gearbox unit dipstick and ensure the oil reaches the top level mark, if necessary
top up with EP90 gear oil.
Replace the spark plug cap.
OPERATION
EVERY
DAY
EVERY
WEEK
EVERY
MONTH
EVERY 6
MONTHS
EVERY 12
MONTHS
Engine
Check engine oil level 10w/40
See separate engine manual
X X
Gearbox
&
Controls
Check gearbox oil level EP90
X X
Check nuts & bolts
X X
Ensure clutch cable has free play
X
Check tyre pressure (20psi)
X X
Lubricate control cable/linkages
X
Check control cable operation
X
Check operation of safety devices
X
Change gearbox oil EP90
X
Grease gear speed detent ball
X X
Scythe
Cutter Bar
Lubricate blades
X
Check for loose bolts
X
*
Pressure washing machines removes lubricating grease as well as dirt. It is imperative all
linkages, especially the gear speed lever detent ball, are kept well greased otherwise they will
becomedifculttooperateandcausedamage.
*
DO NOT turn the machine on its side for cleaning.
*
Before storing machine always leave the Clutch Lever pulled in and secured with the Locking
Clip to prevent sticking of the clutch plates.
*
DO NOT allow maximum engine speed to exceed 3600rpm.
