BD FACSFlow Supply System User’s Guide40
Sheath filter
components
Removing the old
filter
To remove the old filter:
1. Place the cytometer in standby mode.
2. Remove the sheath filter assembly by pressing the
quick-disconnect on both sides of the filter assembly, and
pulling it out of the holder on the sheath plenum enclosure.
3. Over a sink or beaker:
• Remove the vent line from the filter and set it aside.
• Remove the filter base and set it aside.
4. Discard the used filter assembly in an appropriate receptacle.
Item Description
1 Filter base
2Filter
3 Quick-disconnect
4 Fluid line
5Vent line
6Vent cap
1
2
3 4
5 6
