The Front Panel of the S1218-16P-330 Consists of 16-Port 10/100M Auto-Negotiation
Ethernet RJ45 Ports, 2-Port Gigabit TP/SFP Combo Port. The LED indicators are also on
located on the panel.
The Front Panel of the S1226-24P-330 Consists of 24-Port 10/100M Auto-Negotiation
Ethernet RJ45 Ports, 2-Port Gigabit TP/SFP Combo Port. The LED indicators also on
located on the panel.
• Port-based VLAN
S1210-8P-150/S1218-16P-330/S1226-24P-330 have one feature called Port-based
VLAN. Where switching the DIP to the “on” position,PoE ports can not communicate with
each other ,PoE ports only communcate with the uplink ports.
(Note: Please turn off the device before setting)
Port status indicator
24*10/100Mbps PoE RJ45，PoE priority：Port 1 > 2 >3 >...>24
2*10/100/1000Mbps RJ45 & 2*1000Mbps share SFP slots
Port status indicator
2*10/100/1000Mbps RJ45 & 2*1000Mbps share SFP slots
PoE priority：
Port status indicator
1*10/100/1000Mbps RJ45 & 1*1000Mbps share SFP slots
