CASCADIA
6201 6202
ASSEMBLY INSTRUCTIONS
3
BDIUSA.COM CUSTOMERSERVICE@BDIUSA.COM
Step 3
Attach 2nd Leg and Horizontal Bar
Insert tab on Horizontal Bar (G) into
notch on 2nd Leg. Attach Leg to
Table Assembly (D) using Screws (B)
and tighten with Hex Driver (A).
Attach
Horizontal Bar (G) to 2nd Leg
using
Screws (C) and tighten with
Hex Driver (A).
G
C
A
F
F
B
A
B
F
D
Step 4
Adjust Levelers as necessary
Turn Desk or Console over onto Legs.
Position Desk or Console as desired
then turn black puck levelers by hand
to adjust as necessary.
Turn black puck leveler by hand
to adjust as necessary.
Recommended
2-person Step
