ASSEMBLY
STEP 2. ATTACH BASE RAIL & LEGS TO CABINET
With help from another person carefully lay the
(C1) Cabinet onto its back. Attach (C7) Base Rail
to the bottom of the cabinet using 4 (H2) Screws.
Tighten with (T1) Hex Wrench.
Attach both (C6) Legs to the bottom of the
(C1) Cabinet using 8 (H3) Screws. Tighten with
(T1) Hex Wrench.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H2-SCREW 4
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H3-SCREW 8
2 PERSON TASK
C7
H2
H2
H2
H2
C1
C6
C6
C1
H3
H3
H3
H3
