Be Cool BC9KL2201FW - Installation and Adjustment

S. 19
SCHEMATIC REPRESENATION
INSTALLATION AND ADJUSTMENT
Warning: before using the mobile air conditioner, let it stand straight for at least
twohours.
When moving the device, make sure to keep it in an upright position.
Place the air conditioner in a flat and dry place and keep above 50 cm between
themachine and the surrounding objects or walls.
1. Handle
2.
Air
inlet
grid
3.
Control
panel
4.
Castor
5.
Adjustable
slats
6.
Exhaust
air
7.
Water
drainage
8.
Air
inlet
grid
