18
19
Features Operation
UNIT GROUNDING
Starting the Generator
FILLING OIL
MODEL BE-12000ER
AC OUTPUT
Frequency 60Hz
Voltage 120/240V
Rated Power (W) 9500
Max. Power (W) 12000
ENGINE
Specification
Single cylinder, forced air cooling,
4 strokes
Rpm 3600r/min
Fuel Gasoline
Engine Oil Capacity 0.42 Gal /1.6L
Spark Plug Type F7TC/F7RTC (N9YC/RN9YC)
Spark Plug Clearance 0.7 mm
Valve Clearance (inlet/outlet) 0.05/0.07 mm
Igniting Mode T.C.I.
Starting Mode Recoild start/Electric start
Displacement 622cc
WEIGHT (only for reference)
Net Weight 315lb/143kg
OVERALL DIMENSIONS (excluding packing box)
L x W x H (mm) 800 x 620 x 650
Capacity of Fuel Tank 12 Gal / 48L
NOISE (according to European Directive 2000/14/EC with
amendment 2005/88/EC)
Measured Sound Pressure Level 78 dB (A)
Measured Sound Power Level 98 dB (A)
Variable Noise Level 2 dB (A)
Guaranteed Sound Power Level 100 dB (A)
Place the machine outdoors. Use wire of no less than 2.5mm to ensure
the grouding terminal is connected to the ground. One end of the wire
is pressed below the butterfly nut of the unit, while the other end is
connected with a metal object (nail or rod) that has been inserted into the
ground.
Remove the oil dipstick and fill the unit with oil. Refer to the table on
page 18 for the amount of oil needed. Use a funnel to avoid spillage. We
reccomend using SAE 10W30 oil for our products.
FEATURES OPERATION
