Beacon S242P - 8 Specification

S242P User Manual
14
l SPECIFICATION
8.1 SPECIFICATION
LCD panel 23.6”, TFT color LCD, AG, Hard coating
Brightness(Typ.) 400 cd/m
2
Contrast 1000:1
response speed 15ms
Viewing angle Horizontal&Vertical:178°atΦ=0°,90°,180°,270° CR >10
Pixel pitch 0.2715 mm x 0.2715 mm
Horizontal
scanning frequency
31~80 kHz
Vertical
scanning frequency
50~76 Hz
Resolution 1920 x 1080
Support color 1.07 Billion
Power supply DC：24V(4.2A)
Power consumption Max：45 W
Input interface VGA 15 pin D-sub，0.7 Vp-p，separate sync
DVI 24pin, DVI-D，TDMS signal
SDI BNC，75Ohm terminated
CVBS
BNC, 75Ohm terminated （ Support : PAL/
NTSC/SECAM）
S-VIDEO DIN-4, 1VppY-signal, +/-300mV C-signal
YPbPr/RG
B
BNC, 1Vpp Y signal, +/-350mV Pb,Pr signal
Output interface CVBS, YPbPr, S-VIDEO, DVI, SDI
Service interface RS232 D-SUB 9PIN
Plug and Play VESA DDC 2B
Weight 6.0kg
Temperature Operating：0°C ~ 40°C
Store：-20°C ~ 60°C
Humidity 30%~80% R.H. non-condensing
