S242P User Manual
16
8.6 YPbPr/RGB CONNECTOR
Y/G Pb/B Pr/R
Pin Signal
1 Y/G Pb/B Pr/R
2 GND GND GND
8.7 PRESET TIMING
l VGA/DVI preset timing
Video
Formats Horizontal Frequency (kHz) Vertical Frequency (Hz)
Pixel Clock (MHz)
720 x 400 31.5 70.1 28.3
640 x 480 31.5 59.9 25.2
800 x 600 37.9 60.3 40.0
1024 x 768 48.4 60.0 65.0
1280 x 1024 64.0 60.0 108.0
1600 x 1200 75.0 60.0 162.0
1920 x 1080 66.6 59.9 138.50
1920 x 1080 67.0 60.0 172.750
l RGB/YPbPr preset timing
Video Formats Horizontal Frequency (kHz)
Vertical Frequency (Hz) Pixel Clock (MHz)
752 x 582i/50Hz 15.625 50.0 14.1875
480i/60Hz 15.734 59.940 13.5
576i/50Hz 15.625 50.0 13.5
480p/60Hz 31.469 59.940 27.0
576p/50Hz 31.25 50.0 27.0
720p/50Hz 37.50 50.0 74.250
720p/60Hz 45.00 60.0 74.250
1080i/50Hz 28.125 50.0 74.250
1080i/60Hz 33.750 60.0 74.250
1080p/50Hz 56.250 50.0 148.50
1080p/60Hz 67.500 60.0 148.50
l CVBS, S-VIDEO preset timing
Video Formats Horizontal Frequency(kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
PAL(576i) 15.625 50.0 13.50
NTSC(480i) 15.734 59.940 13.50
