Beam E4 - Page 9

2 pcs
Flat Head Bolt, 2x8mm
4 pcs
Main Blade Holder Set
Linkage Ball,
4.7x4.5mm (2 pcs)
Countersunk Screw,
2x7mm (2 pcs)
Ball Bearing, #693zz (2 pcs)
Main Blade Holder
Ball Bearing,
#MR63zz
(2 pcs)
Spacer Collar,
4x4mm (2 pcs)
Main Rotor Hub
Seesaw
Ball Bearing,
#MR52zz (8 pcs)
Countersunk Screw,
2x7mm (6 pcs)
Flat Head Bolt,
2x8mm (2 pcs)
Head Stopper
Socket Head Bolt,
2x4mm (1 pc)
Head Stopper Set
Ball Bearing,
#MR52zz (4 pcs)
Self Tapping Screw,
1.7x7mm (2 pcs)
Flat Head Bolt,
2x8mm (2 pcs)
Washout Arm
Washout Link
Linkage Ball,
4.7x4.5mm (4 pcs)
Countersunk Screw, 2x8mm (2 pcs)
Linkage Ball,
4.7x5.5mm (2 pcs)
Feathering Shaft
O-Ring hard (2 pcs)
Spacer,
5x1.5mm (2 pcs)
Nylon Nut,
3mm (2 pcs)
Nut, 2mm (1 pc)
Socket Head Bolt,
2x11mm (1 pc)
Set Screw,
3x3mm (2 pcs)
Main Mast Lock
Main Mast
Washout Arm Set
Seesaw Mixing Arm Set
Seesaw
Mixing Arm
Seesaw Set
Countersunk Screw, 2x8mm
2 pcs
Countersunk Screw, 2x7mm
8 pcs
Set Screw, 3x3mm
2 pcs
Socket Head Bolt, 2x4mm
1 pc
Nut, 2mm
1 pc
Ball Bearing, #693zz
2 pcs
Washout Base
Spacer, 3x2.5mm (2 pcs)
Ball Bearing, #MR52zz
12 pcs
Nylon Nut, 3mm
2 pcs
3-1
R
e
d
R
e
d
B
l
u
e
R
e
d
R
e
d
B
l
u
e
B
l
u
e
B
l
u
e
Main Rotor Head
Socket Head Bolt, 2x11mm
1 pc
Self Tapping Screw, 1.7x7mm
2 pcs
Ball Bearing, #MR63zz
R
e
d
Swashplate
Assembly
O-Ring soft (2 pcs)
