• Press and hold the ¢ button to drive the beam down to your desired
grade in the X1 direction.
• Press and hold the button to drive the beam up to your desired
grade in the Y1 direction.
• Press and hold the £ button to drive the beam down to your desired
grade in the Y1 direction.
Notes:
• Press the auto/manual button again to
enter back into automatic leveling mode.
• Entered grades are not saved when the
unit is turned off. The laser will always
automatically self-level when
turned on.
(See Annex A for manual
slope set-up procedure)
— 11 —
X2
X1
Y1
Y2
To Next Page
