— 17 —

7.1.2 X-axis:

1. Follow steps 1 to 4 of procedure 7.1.1 above, substituting the X-axis for

the Y-axis.

2. If the calibration error is within the stated specifications of ±2.0mm @

30m then no calibration is required. If the calibration is outside of this

specification do not move the laser and proceed with the calibration

procedure for the X-axis outlined in 7.2.2

7.2 Horizontal Calibration Adjustment:

7.2.1 Y-axis:

1. Press and hold the

and

buttons on the laser control panel for about

3 seconds. The anti-drift LED will start flashing to indicate that the laser

is in Y-axis calibration mode.

2. Use the

or buttons to adjust the height of the beam on the target

until it is at true level or within the calibration specifications of the laser.

3. Press and hold the

and

buttons on the laser control panel for about

3 seconds to save the calibration data and exit Y-axis calibration mode.

The laser will return to horizontal leveling mode and the anti-drift LED

will turn off.

Bear POLAR User Manual
