71020 & 70554 Chipper Shredder Owners ManualPage 18
Service and Maintenance
5.13 SERVICE ACCESSORIES
Towable PTO
Discharge Screens
Fine 70703 70703
Medium 70531 70531
Coarse 70332 70332
Wet Debris Screen 70559 70559
Goggles (one pair supplied with the screen) 17842 17842
Leaf Tamper 70649 70649
Chipper Blades 72493 72493
Shredder Kit 70972 70972
Light Kit 70454 70454
Collection Bag 17854 17854
Part Number
Description
Service Accessories
5. Loosen the bolts mounting the jack shaft pillow block
and move the shaft towards the frame so belts can be
removed.
6. Install new belts and make sure pulleys are alligned
to within 1/16". If not adjust pulleys.
7. Slide jack shaft away from frame. Tighten bolts so
that 1/4" deflection at center of belt span is obtained
with 10 lb. force applied at the center of the span.
Make sure the jack shaft is aligned parallel to the
rotor shaft before tightening the pillow block bolts.
8. Reinstall belt shields and guards. Install PTO shaft
and tighten the two set screws. Install PTO shield.
Never run PTO shaft without all shields in place.
5.11 TRAILER SERVICE TIPS
1. Check wheel bolt torque every 10 hours of towing use.
2. Check air pressure in tire every 10 hours. Fill to
recommended pressure on tire sidewall.
3. Check and repack wheel bearings with grease every
year.
5.12 ADDITIONAL SERVICE AND
MAINTENACE TIPS
1. Service engine according to engine owners manual.
2. Every 10 hours of operation, all bolts and other
fasteners should be checked for correct torque.
3. The PTO model has 2 greasable bearings on the rotor
shaft. There are also two greasable bearings on the
main jack shaft under the small belt guard. These
bearings need only to be greased once per year under
normal working conditions. Be carefull not to damage
seals on the bearing by over greasing.
4. The PTO shaft also has 4 grease zerks that can be
lightly greased every 50 hours of use.
5. Remove the discharge screen (all models) daily to
avoid material buildup under normal mounting sur-
faces. Clean away material and reinstall screen.
