20
N.B. In case there are two cameras or more operating in the system, besure
each camera and its corresponding sensor mat are far away from each other
and placed in separate rooms to avoid interfering each other and creating
false alarm.
BSM-1
BSM-2
6. When parents need to take baby out from crib for feeding or other purpose, to
avoid breathing alert alarm, short press the alarm hold button 29 . This button can
be pressed before or after taking out the baby, but such action must be performed
within 20 sec, or otherwise the alarm would still sound. To stop alarm in PU, short
press hold button 29 again. Upon placing back the baby into crib, the sensor mat
will automatically resume monitoring the baby movement after 20 seconds.
7. When the baby’s movement increases as he grows older, he may move away
from the sensor mat and cause false alarm. Additional movement sensor mat can
be connected to increase the coverage.
