Bebcare Motion - Controls Layout

CONTROLS LAYOUT
3
27
29
28
Parent Unit (PU)
Movement Sensor Mat
Camera
Camera pan left button
(left button in menu mode)
Camera pan right button
(right button in menu mode)
Power ON/Charging indicator
Talk back button
(OK button in menu mode)
TFT colour screen
USB socket
Power ON/OFF/Vibration switch
Volume up/down button
Speaker
Menu button
Pairing button
Movement indicator
Movement sensitivity adjustment knob
Alarm hold button
Power ON/OFF button
Power ON indicator
Transmit indicator
Night light
Microphone
USB socket
SD card slot
Night light intensity up button
Night light intensity down button
Speaker
Pairing button
LED level meter
Microphone
Camera tilt up button
(up button in menu mode)
Camera tilt down button
(down button in menu mode)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
