Extended point to retracted point with programming unit
There is no shading solution length adjustment with this limit position setting.
Set both switches to the programming setting.
Open to the desired extended limit position.
Press the programming button of the programming unit for 3 seconds.
▻ The tubular drive confirms.
Then open to the desired retracted limit position.
Press the programming button of the programming unit for 3 seconds.
▻ The tubular drive confirms.
► The limit positions are now set.
Extended point to retracted stop with programming unit
Set both switches to the programming setting.
Open to the desired extended limit position.
Press the programming button of the programming unit for 3 seconds.
▻ The tubular drive confirms.
Then retract to the permanent upper stop.
▻ The tubular drive switches off automatically.
► The limit positions are now set.
