Becker E12 - Technical Data Dia. 35; Technical Data Dia. 45

Technical data dia. 35
Tubular drive P5-16 P5-20 P5-30 P9-16
Model E12
Type C PS V1
Rated torque [Nm] 5 5 5 9
Output speed [rpm] 16 20 30 16
Limit switch range 64revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 85 115 115 110
Rated current consumption [A] 0.36 0.47 0.47 0.47
Operating mode S24min
Degree of protection IP44
Min. tube inside diameter [mm] 37
Emission sound pressure level
[dB(A)]
≤70
Technical data dia. 45
Tubular drive R8-17 R12-17 R20-17 R30-17 R40-17 R50-11
Model E12
Type C PS+ V1
Rated torque [Nm] 8 12 20 30 40 50
Output speed [rpm] 17 17 17 17 17 11
Limit switch range 64revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 100 110 160 205 260 240
Rated current consumption
[A]
0.45 0.50 0.75 0.90 1.15 1.10
Operating mode S24min
Degree of protection IP44
Min. tube inside diameter
[mm]
47
Emission sound pressure
level [dB(A)]
≤70
21-en
