Becker E12 - Technical Data Dia. 58

Technical data dia. 58
Tubular drive L50-17 L60-11 L60-17 L70-17
Model E12
Type C PS+ V1
Rated torque [Nm] 50 60 60 70
Output speed [rpm] 17 11 17 17
Limit switch range 64revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 315 265 380 430
Rated current consumption
[A]
1.40 1.20 1.75 1.90
Operating mode S24min
Degree of protection IP44
Min. tube inside diameter
[mm]
60
Emission sound pressure
level [dB(A)]
≤70
Tubular drive L80-11 L80-17* L120-11
Model E12
Type C PS+ V1
Rated torque [Nm] 80 80 120
Output speed [rpm] 11 17 11
Limit switch range 64revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 310 470 435
Rated current consump-
tion [A]
1.40 2.10 1.90
Operating mode S24min
Degree of protection IP44
Min. tube inside diameter
[mm]
60
Emission sound pressure
level [dB(A)]
≤70
*) This tubular drive is not yet available.
22-en
