Technical Data CP9030
Cable and jumper configurations
Advantech SBC
CLOSED
J207, J208, J209, J210, J214, J239, J240, J245
LO100 (CP9030_4) for 15 inch display
OPEN
It is essential that the remaining jumpers are OPEN to avoid damaging the
CP-Link card or the graphic card / SBC!
Ribbon Cable ST205 (50 pin RM2.0)
Pin assignment 1:1
Pin 1-6 of the post connector remain open
Bayview 50 / 52 Graphic Card
CLOSED
J201, J202, J206, J209, J212, J214, J217, J220, J223, J226, J229, J232,
J235, J238, J241, J247
LO100 (CP9030_4) for 15 inch display
OPEN
It is essential that the remaining jumpers are OPEN to avoid damaging the
CP-Link card or the graphic card / SBC!
Ribbon Cable ST202 (50 pin RM2.54)
Pin assignment 1:1
Pins 1-4 of the ribbon cable must be disconnected
Boser HS6237 SBC
CLOSED
J201, J202, J203, J204, J208, J239
LO100 (CP9030_4) for 15 inch display
OPEN
It is essential that the remaining jumpers are OPEN to avoid damaging the
CP-Link card or the graphic card / SBC!
Ribbon Cable ST205 (50 pin RM2.0)
Pin assignment 1:1
Pin 1-6 of the post connector remain open
Pins 1, 2 and 35 of the ribbon cable must be disconnected
16 CP9030 / CP9035
