CP9030 card pin assignments
ST202 / ST204 (Display connection)
The assignment varies according to the programming.
PIN Signal PIN Signal PIN Signal
1
nc
18
G2
35
GND
2
nc
19
G3
36
B6
3
nc
20
GND
37
B7
4
DISPON
21
G4
38
GND
5
nc
22
G5
39
R0
6
GND
23
GND
40
R1
7
ENAB
24
G6
41
GND
8
nc
25
G7
42
R2
9
GND
26
GND
43
R3
10
HSYNC
27
B0
44
GND
11
VSYNC
28
B1
45
R4
12
GND
29
GND
46
R5
13
DISPCLK
30
B2
47
nc
14
GND
31
B3
48
R6
15
G0
32
GND
49
R7
16
G1
33
B4
50
nc
12
49 50
17
GND
34
B5
IC201
indicates the programmed graphic card adaptation and its version.
IC500
indicates the revision of the BECKHOFF firmware for the CP-Link card.
ST305 (Keyboard switching for the next CP-Link card)
PIN Signal PIN Signal
1
PCKCI
6
5V
2
PCKDI
7
GND
3
5V
8
GND
4
5V
9
GND
12
910
5
5V
10
G
ND
ST304 (External keyboard connection)
PIN Signal PIN Signal
1
EKCI
6
5V
2
EKDI
7
GND
3
5V
8
GND
4
5V
9
GND
12
910
5
5V
10
GND
ST306 (PS/2 mouse connection)
PIN Signal PIN Signal
1
PCMOCI
6
5V
2
PCMODI
7
GND
3
EMOCI
8
GND
4
EMODI
9
GND
12
910
5
5V
10
GND
