Technical Data CP9030
SW500 (Index setting)
PIN Signal
1
SW1
2
SW2
3
SW3
1
ON DIP
2
3
4
4
SW4
SW400 (Address setting)
Segment
8 7 6 5 4 3 2 1
C800
0 1 1 0 1 1 1 1
C880
0 1 1 0 1 1 1 0
C900
0 1 1 0 1 1 0 1
C980
0 1 1 0 1 1 0 0
CA00
0 1 1 0 1 0 1 1
CA80
0 1 1 0 1 0 1 0
CB00
0 1 1 0 1 0 0 1
CB80
0 1 1 0 1 0 0 0
CC00
0 1 1 0 0 1 1 1
CC80
0 1 1 0 0 1 1 0
CD00
0 1 1 0 0 1 0 1
CD80
0 1 1 0 0 1 0 0
CE00
0 1 1 0 0 0 1 1
CE80
0 1 1 0 0 0 1 0
CF00
0 1 1 0 0 0 0 1
CF80
0 1 1 0 0 0 0 0
D000
0 1 0 1 1 1 1 1
D080
0 1 0 1 1 1 1 0
D100
0 1 0 1 1 1 0 1
D180
0 1 0 1 1 1 0 0
D200
0 1 0 1 1 0 1 1
D280
0 1 0 1 1 0 1 0
D300
0 1 0 1 1 0 0 1
D380
0 1 0 1 1 0 0 0
D400
0 1 0 1 0 1 1 1
D480
0 1 0 1 0 1 1 0
D500
0 1 0 1 0 1 0 1
D580
0 1 0 1 0 1 0 0
D600
0 1 0 1 0 0 1 1
D680
0 1 0 1 0 0 1 0
D700
0 1 0 1 0 0 0 1
D780
0 1 0 1 0 0 0 0
D800
0 1 0 0 1 1 1 1
D880
0 1 0 0 1 1 1 0
D900
0 1 0 0 1 1 0 1
D980
0 1 0 0 1 1 0 0
DA00
0 1 0 0 1 0 1 1
DA80
0 1 0 0 1 0 1 0
DB00
0 1 0 0 1 0 0 1
DB80
0 1 0 0 1 0 0 0
ON DIP
12
3
45678
"1"=ON - "0"=OFF
DC00
0 1 0 0 0 1 1 1
