Technical Data CP9035
ST401 (Voltage connection for the CP-Link card)
PIN Signal
1
12V
2
GND
3
GND
4
5V
ST303 external connection
ST303
PIN
RS232
D-SUB 9
female*
Touchscreen
D-SUB 9
female
Keyboard
DIN 5
Keyboard
PS/2
Mouse
PS/2
1
9
2
8
3
7
4
6
5
8
6
2
7
4
8
1
5
9
10
1
11
2
12
3
13
4
14
7
15
3
16
6
17
2
1
18
19
5
20
21
22
5
23
24
25
26
* The RS232 and Touchpad connections are identical
