Product overview
CX8030 / CX803118 Version: 1.6
CX8030 as slave
The CX8030 can also be configured as a slave. Unlike the CX8031, where 3 virtual slaves are available, only
one real slave can be used. The CX8030 can operate either as a master or as a slave, but not both at the
same time.
Technical data - PROFIBUS CX8030
Data transfer rate 9,6k; 19,2k; 93,75k; 187,5k; 500k; 1,5M; 3M; 6M; 12
MBaud
Bus interface 1 x D-sub socket, 9-pin
Number of slaves 1
max. process image 240 Byte In / 240 Byte Out
CX8031
Technical data - PROFIBUS CX8031
Fieldbus PROFIBUS DP, DP-V1
Data transfer rate 9,6k; 19,2k; 93,75k; 187,5k; 500k; 1,5M; 3M; 6M; 12
MBaud
Bus interface 1 x D-sub socket, 9-pin
Extendable process image Up to 3 virtual slaves in addition
max. process image 4 slaves x (240 bytes in / 240 bytes out)
Autobaud Yes
Protokoll
PROFIBUS-DP Slave Yes
PROFIBUS-DP (virtual slave) 4 (3 virtual PROFIBUS Nodes)
ADS Interface Yes (only via Ethernet)
Services
PROFIBUS DP
DPV1 Yes
Diagnosis/Status/Alarm
TC LED Yes, green/red
BF LED Yes, green/red
DIA LED Yes, green/red
diagnostic notice Yes
