4.4 Technical data - PROFIBUS
System data PROFIBUS (CX8030, CX8031)
Number of I/O
modules
100 with repeater
Number of I/O
points
approx. 6.000, depending on the master
Transmission
medium
screened copper cable, 2 x 0.25 mm²
Cable length 1200 m 1000 m 400 m 200 m 100 m
Data transfer rate 9,6/19,2/93,75
kBaud
187,5 kBaud 500 kBaud 1500 kBaud 3, 6, 12 MBaud
Topology Line topology
CX8030
Technical data - PROFIBUS CX8030
Fieldbus PROFIBUS DP, DP-V1
Data transfer rate 9,6k; 19,2k; 93,75k; 187,5k; 500k; 1,5M; 3M; 6M; 12
MBaud
Bus interface 1 x D-sub socket, 9-pin
Bus devices max. 125 with repeater
max. process image 30,5 kByte in / 30,5 kByte out
Protokoll
PROFIBUS-DP Yes
PROFIBUS-FMS No
ADS Interface Yes (only via Ethernet)
Services
PROFIBUS DP
DPV1 class 1 Yes
DPV1 class 2 No
DPV2 MC No
Redundancy No
Muti Master No
FDL No
S5 AG-AG No
Activating slaves via ADS Yes
PKW No
Diagnosis/Status/Alarm
TC LED Yes, green/red
BF LED Yes, green/red
DIA LED Yes, green/red (no function)
