Programming
CX8030 / CX8031 61Version: 1.6
Manufacturer-specific diagnosis
The structure of the manufacturer-specific diagnosis may be found in the documentation for the DP slave.
7.4.1.4 Uploading the Configuration
During operation the PROFIBUS can be scanned for new devices via ADS [}54] Read:
ADS-Read parameters Meaning
Net-ID
Net-ID of the master (see the device's ADS [}54] tab)
Port 200
IndexGroup 0x00yyF830 (yy = station address, Beckhoff devices
provide the same information as other devices)
IndexOffset 0
Length 1538
Data Configuration data of the slave
If the device is from another manufacturer, or if the IndexGroup indicates that Beckhoff devices are to
behave in exactly the same way as devices from other manufacturers, then the following information is
returned in the ADS read response:
Offset Description
0 -1 1
2 - 7
DP diagnostic data bytes 0-5 (see Slave Diagnosis
[}58])
8 - 251 DP configuration data (CfgData)
