5.1.8.8 DPV1 Error Codes
In the event of an incorrect DPV1 access, the slave replies with 4 bytes of data (any values that are not
described here are not defined in the DPV1 standard, and are therefore to be found in the slave’s manual).
byte 0 DPV1 service
0xD1 Data_Transport
0xD7 Initiate
0xDE Read
0xDF Write
byte 1 Error_Decode
0x80 DPV1
0xFE FMS
0xFF HART
byte 2 Error_Code_1
Error-Class (bits 4-7) Error-Code (bits 0-3)
0x0A 0x00 Application, Read Error
0x01 Application, Write Error
0x02 Application, Module Failure
0x08 Application, Version Conflict
0x09 Application, Feature Not Supported
0x0B 0x00 Access, Invalid Index
0x01 Access, Write Length Error
0x02 Access, Invalid Slot
0x03 Access, Type Conflict
0x04 Access, Invalid Area
0x05 Access, State Conflict
0x06 Access, Access Denied
0x07 Access, Invalid Range
0x08 Access, Invalid Parameter
0x09 Access, Invalid Type
0x0C 0x00 Resource, Read Constrain Conflict
0x01 Resource, Write Constrain Conflict
0x02 Resource, Busy
0x03 Resource, Unavailable
