Parameterization and commissioning
EL6731 127Version: 2.8
5.1.8.9 ADS Error Codes
Error code Meaning
0x1129 IndexOffset too large during reading of the FC310x/EL6731 diagnostic data
0x112B IndexOffset too large during reading of the slave diagnostic data
0x112D Invalid station address during reading of the slave diagnostic data
0x2023 Invalid IndexOffset during resetting of the FC310x/EL6731 diagnostic data
0x2024 Invalid data during resetting of the FC310x/EL6731 diagnostic data
0x2025 Invalid data length during resetting of the FC310x/EL6731 diagnostic data
0x2101 DPV1-C1-Read: cyclic connection to slave not yet established
0x2102 PKW-Read: only data lengths 2 and 4 are permitted
0x2103 PKW-Read: slave not in data exchange
0x2105 PKW-Read: slave does not support PKW
0x2106 PKW-Read: Incorrect IndexOffset
0x2107 PKW-Read: Incorrect IndexGroup
0x2109 DPV1-C1-Read: FDL fault (no response etc.)
0x210A DPV1-C1-Read: syntax error (DPV1 syntax not correct)
0x210B DPV1-C1-Read: DPV1 fault (4 bytes error code in the diagnostic data of the slave)
0x210C PKW-Read: syntax error
0x210D PKW-Read: PKW error
0x210E PKW-Read: incorrect data type
0x210F DPV1-C1-Write: cyclic connection to slave not yet established
0x2110 PKW-Write: only data lengths 2 and 4 are permitted
0x2111 PKW-Write: Incorrect IndexOffset
0x2112 PKW-Write: slave does not support PKW
0x2113 PKW-Write: Incorrect IndexGroup
0x2114 Read general: Incorrect IndexGroup
0x2115 DPV1-C1-Write: FDL fault (no response etc.)
0x2116 DPV1-C1-Write: syntax error (DPV1 syntax not correct)
0x2117 DPV1-C1-Write: DPV1 fault (4 bytes error code in the diagnostic data of the slave)
0x211C Read general: Incorrect IndexGroup
0x211D SetSlaveAdress: Incorrect IndexOffset
0x211E FDL-AGAG-Write: Incorrect IndexOffset
0x211F FDL-AGAG-Read: Incorrect IndexOffset
0x2120 FDL-AGAG-Write: Incorrect length
0x2121 SetSlaveAddress: Incorrect length
0x2122 FDL-AGAG-Read: Incorrect length
0x2131 Write general: wrong IndexGroup
0x2132 Write general: wrong IndexGroup
0x2137 PKW-Read: WORD received, but read data length does not equal 2
0x2138 PKW-Read: DWORD received, but read data length does not equal 4
0x2139 PKW-Read: unknown AK received (1.2 or 7 expected)
0x213A PKW-Read-Array: WORD received, but read data length does not equal 2
0x213B PKW-Read-Array: DWORD received, but read data length does not equal 4
0x213C PKW-Read-Array: unknown AK received (4.5 or 7 expected)
0x213D PKW-Write-Array: unknown AK received (2 or 7 expected)
0x213E PKW-Write: unknown AK received (1 or 7 expected)
0x213F PKW-Write: unknown AK received (2 or 7 expected)
0x2140 PKW-Write-Array: unknown AK received (1 or 7 expected)
0x2142 SetSlaveAddress: wrong parameter during setting of address in slave mode
0x2144 Incorrect IndexGroup in ReadWrite
0x2147 DPV1-C2-Initiate: MSAC_C2 is not activated
0x2148 Incorrect IndexGroup in Read
0x2149 Incorrect IndexGroup in Write
