Parameterization and commissioning
EL6731128 Version: 2.8
Error code Meaning
0x214E DPV1-C2-Read: MSAC_C2 is not activated
0x214F DPV1-C2-Write: MSAC_C2 is not activated
0x2150 DPV1-C2-DataTransport: MSAC_C2 is not activated
0x2151 DPV1-C2-Read: FDL fault (no response etc.)
0x2152 DPV1-C2-Read: connection aborted
0x2153 DPV1-C2-Read: DPV1 fault (4 bytes error code in the diagnostic data of the slave)
0x2154 PKW-ReadNoOfElements: length must equal 1
0x2155 PKW-ReadNoOfElements: PKW is not activated
0x2156 PKW-ReadNoOfElements: axis number is too great
0x2157 PKW-ReadNoOfElements: slave not in data exchange
0x2158 PKW-ReadNoOfElements: unknown AK received (6 or 7 expected)
0x215A DPV1-C2-Write: FDL fault (no response etc.)
0x215B DPV1-C2-Write: connection aborted
0x215C DPV1-C2-Write: DPV1 fault (4 bytes error code in the diagnostic data of the slave)
0x215D DPV1-C2-DataTransport: FDL fault (no response etc.)
0x215E DPV1-C2-DataTransport: connection aborted
0x215F DPV1-C2-DataTransport: DPV1 fault (4 bytes error code in the diagnostic data of the slave)
0x2163 DPV1-C2-DataTransport: Incorrect IndexOffset
0x2600-0x26F
F
AK 7 (error) during PKW processing, error code in low byte
0x2700-0x27F
F
Fault during DPV1 processing, 4 bytes error code in the slave diagnostic data, byte 3 of the error code (error class) is in
Low byte
"Not expected" error codes from the PROFIBUS slave in 0x28xx
Error code Meaning
0x0 OK (is usually not passed on by the terminal)
0x1 UE = User Error
0x2 RR = No resources
0x3 RS = SAP not enabled
0x8*** DL = Data Low (normal case with DP)
0x9*** NR = No response data ready
0xA DH = Data High (DP diagnosis pending)
0xC RDL = Data not received and Data Low
0xD RDH = Data not received and Data High
***)
DL and NR are handled by the EL6731
