26
6. CAMERA INSTALLATION
The camera is positioned above the number plate without obscuring, and must be located as centrally as possible in the vehicle.
Remove the original pilot of the slot plate to identify the most suitable location to the right, left or right on the pilot
bracket plate. In the trunk, find out how to wire the camera, allow the setting of the camera and connect it to the son
of the original vehicle as shown previous pages.
After choosing the best camera location, drill a hole with a diameter of 6 mm.
We advise you to protect the holder of an adhesive (adhesive type painter) to prevent damage during drilling. A light
sanding may be required after drilling the hole for trimming the edge of the hole so as not to damage the insulation
of the cable from the camera.
Remove the nut on the threaded rod of the camera, pass the thread of the camera (microphone connector) through the
hole. Collect this thread in the trunk, insert the nut and screw on the threaded rod. Tightening must be strong enough
to ensure good sealing and holding the camera, be careful any time not to tighten which could break the rod filtée
camera.
1
2
3
GROUND
LOW PLACE
VERTICAL CAMERA
