Figure 2 - Mountain pedelec example
N° Components N° Components
1 Saddle 7 Derailleur
2 Seat post 8 Cockpit (Stem & Handlebar)
3 Frame 9 Crank
4
Integrated Battery HIDDEN
POWER
10 Motor
5 Chain 11 Fork
6 Cassette
URBAN/TREKKING
Figure 1- City/Trekking pedelec example
N° Components N° Components
1 Saddle 14 Front lighting
2 Seat post 15 Front mud guard
3 Luggage racks 16 Fork
4 Rear lighting 17 Fix for front mudguard
5 Rear mud guard 18 Tire
6 Cassette/Internal gear 19 Brake caliper
7 Kickstand 20 Disc Brake
8 Derailleur/Internal gear 21 Rim
9 Chain 22 Front mud guard
10 Chain guard 23
Integrated Battery HIDDEN
POWER
11 Motor 24 Pedal
12 Frame 25 Crank
13 Cockpit (Stem & Handlebar)
