CHAPTER 4
“SimpleBGC GUI” SOFTWARE
OVERVIEW
The SimpleBGC GUI software application enables you to do the following:
•
Update the firmware on your controller
•
Define settings for your specific installation of the controller
•
Tune settings to get the optimal performance for your installation
•
Adjust settings for various modes of operation
USING SimpleBGC GUI
After you start the software and select the correct COM port from the list, click “Connect."
When the connection is established, all board settings and profiles will be loaded into the
software. You can re-load the current board parameters anytime by clicking the “READ”
button.
After adjusting parameters in the software, you should write them to the controller board
by clicking the “WRITE” button. Only the current profile parameters will be saved to the
board. To return to the default settings, select the “USE DEFAULTS” button.
To choose a different profile, select it from the list of profiles located in the upper right
corner of the window. You can store different settings as five different profiles onto the
controller board. You can switch profiles saved on the board by choosing the profile in the
software or by pressing the MENU button, if configured on your controller board.
