English
⋅
Fornax
®
T
17
86107 BA-en/01
Setting the timer
1. Use the "-" and "+" buttons (hour glass symbol)
to set the timer (see casting table, page 26
continue heating / holding time); press the start
button when done.
Adjusting the mould weight
Every time a different mould size is used, the
position of the sliding counterweights on the casting
arm need to be adjusted to properly balance the
weight of the installed mould.
1. Unlock the sliding counterweight by pulling it
upward.
2. Set the tare weight of the mould by sliding the
counterweight accordingly.
The yellow pin the the center of the adjustment
weight or the adjustment bar indicates the set
mould weight on the scale.
3. Lock the sliding counterweight in its position by
pushing it down when finished.
The timer can be reset by pressing the "-" and "+"
buttons simultaneously.
