BEHA UNITEST CHB 15 User Manual

30
Continuity test
UNITEST Clamp Meter CHB 15
Range Beep sound Open Circuit Voltage Overload protection
< 40 V < 0,4 V 600 V
UNITEST Clamp Adapter CHB 10
(40 Hz … 1 kHz)
Range Output Accuracy Sensitivity
0 … 4 A 100 mV/A 5(3 % rdg. + 0,005 A) 0,1 mV/1 mA
0 … 40 A 10 mV/A 5(2 % rdg. + 0,03 A) 0,1 mV/10 mA
0 … 200 A 1 mV/A 5(2 % rdg. + 0,3 A) 0,1 mV/100 mA
Voltage DC
UNITEST Clamp Meter CHB 15
Range Resolution Accuracy Input Impedance Overload protection
400 V 0,1 V 5(2 % rdg.+2 Digits) 10 MV 1000 V
Resistance
UNITEST Clamp Meter CHB 15
Range Resolution Accuracy Open Circuit Voltage Overload protection
40…400V 0,1 V 5(2 % rdg.+2 Digits) 0,4 V 600 V
Frequency (Hz)
Voltage range/UNITEST Clamp Meter CHB 15
(Automatic Range selection)
Range Resolution Accuracy Sensitivity Overload protection
0 … 50 kHz 0,01…10 Hz 5(1 % rdg.+2 Digits) 2 V 600 V
Current range/UNITEST Clamp Meter CHB 35
(Automatic Range selection)
Range Resolution Accuracy Sensitivity Overload protection
40 … 99,9 Hz 0,01 Hz 10 A
500 A
100…999 Hz
0,1 Hz
5(1% rdg.
1 A
1kHz…9,99 kHz 1 Hz
+ 2 Digits)
Current AC
UNITEST Clamp Meter CHB 15
Range Reso- Accuracy Overload
lution 50 Hz/60 Hz 40 Hz … 1 kHz protection
400 V 0,1 V 5(2 % rdg.+2 Digits) 5(3 % rdg.+4 Digits) 800 V
PTDB93468-05.qxd 14.12.2005 9:41 Uhr Seite 30
