Camera Setup and Balancing
a) Detach the quick release plate from the unit and reattach to the
bottom of the camera (Image A). Tighten the screw lightly leaving room
for adjustments.
b) Attach the camera which Is on the quick release plate onto the unit
(image A), Fine tuning the camera and quick release plate by moving it
back and fro and sideway carefully (Image B) so that the camera can
be balance properly* onto the unit. Detach the quick release plate with
camera carefully and tighten all the screws. Reattach onto the unit and
tighten the screw knob lastly. Making sure it is tight but not "too tight" to
avoid internal gears slipping when motors are turn on later.
*Properly balanced camera on the unit should neither tilt upwards nor
sideway when power is NOT turn on. Camera with extendable lens
should have lens in fully extended position.
A. Attach the single sided anti slipping
materials onto the adapter plate.
B. Make sure the camera can be balance
properly in all positions.
Image A
Image B
5
