Beholder DS1 - Installation of special adapter for hard to balance camera; Start up and operation

Start up and operation
A. 1) Only turn on the unit when there is a camera mounted properly on
the stabilizer.
Beholder DS1 utilizing a double IMU sensors and with a 32 bits
processing technology, the stabilizer essentially can be started up and
operated in any reasonable angles.
Installation of special adapter for hard to balance camera
1. Attach the single sided anti slipping materials onto
the adapter plate.
2. Attach the anti slip side onto the base of the
camera (Image 1) and lightly tighten the 1/4"
screw.
3. Attach the whole unit onto the quick release
plate*. (Image 2)
*try different screw anchoring holes for best result,
you might have to try out many times to register the
appropriate anchoring hole for the best balancing
result.
4. Adjust the camera position on the adapter plate,
fine tuning the screw position on the quick release
plate to achieve a perfect balance, repeating
steps A- B.
5. Tighten all screws and knob. Loose space in
between camera, adapter, quick release plate
and the unit will result in rattling noise and shaking
movement while unit is in operation later.
Image 1
Image 2
Finally with camera on the adapter, attach it onto the quick release plate
and insert the whole unit into DS1 main body.
7
