Specications
44 45Quick Start GuideEUROCOM MA6480A/MA6018/MA6008/MA6000M
MA6480A MA6000M MA6018 MA6008
Audio Inputs
Mic / Line inputs 1 & 2
Type
2 x XLR / ¼" TRS combo
jacks 1 x 4-pin Euroblock
in parallel and 1 x 3-pin
Euroblock in parallel
2 x XLR / ¼" TRS
combo jacks
2 x 5-pin Euroblock
inparallel
2 x XLR / ¼" TRS
combo jacks
2 x 5-pin Euroblock
inparallel
2 x XLR / ¼" TRS
combo jacks
2 x 5-pin Euroblock
inparallel
Impedance
Mic: -50 dBV, 600 Ω
Line: 0 dBV, 600 Ω
Electronically balanced
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Inputs 3 – 8
Type —
6 x XLR / ¼" TRS combojacks
6 x 5-pin Euroblock inparallel
6 x XLR / ¼" TRS combojacks
6 x 5-pin Euroblock inparallel
6 x XLR / ¼" TRS combojacks
6 x 5-pin Euroblock inparallel
Impedance —
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Electronically balanced
Auxiliary inputs — 4 x RCA stereo summed 4 x RCA stereo summed 4 x RCA stereo summed
Impedance — -10 dBV, 10 kΩ, unbalanced -10 dBV, 10 kΩ, unbalanced -10 dBV, 10 kΩ, unbalanced
Tel / Page input — 1 x 4-pin Euroblock 1 x 4-pin Euroblock 1 x 4-pin Euroblock
Impedance —
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Mic: -50 to 0 dBV, 600 Ω
Line: -27 to 0 dBV, 600 Ω
Preamp 70 V input — — 1 x 5-pin Euroblock 1 x 5-pin Euroblock
Impedance — — 0 dBV, 600 Ω, balanced 0 dBV, 600 Ω, balanced
Preamp 4  input — — 1 x 5-pin Euroblock 1 x 5-pin Euroblock
Impedance — — 0 dBV, 600 Ω, balanced 0 dBV, 600 Ω, balanced
Phantom power 24 VDC, switchable Inputs 1– 2
24 VDC, switchable
Inputs 1– 8 and Tel / Page
24 VDC, switchable
Inputs 1– 8 and Tel / Page
24 VDC, switchable
Inputs 1– 8 and Tel / Page
Audio Outputs
Amplier output 1 x 4-pin female Euroblock — 1 x 4-pin female Euroblock 1 x 4-pin female Euroblock
LO-Z 2 terminals @ 4 Ω — 2 terminals @ 4 Ω 2 terminals @ 4 Ω
HI-Z
2 terminals @ 70 V / 100 V,
switchable
—
2 terminals @ 70 V / 100 V,
switchable
2 terminals @ 70 V / 100 V,
switchable
Output regulation < 2 dB, no load to full load — < 2 dB, no load to full load < 2 dB, no load to full load
Main mix outputs 1 & 2 —
1 x 3-pin male Euroblock,
Mic/Line switchable
— —
Impedance —
Mic: -36 dBV, 1 kΩ
Line: +4 dBV, 600 Ω
Electronically balanced
— —
Preamp 70 V output — — 1 x 5-pin Euroblock 1 x 5-pin Euroblock
Impedance — — 0 dBV, 600 Ω, balanced 0 dBV, 600 Ω, balanced
Preamp 4 Ω output — — 1 x 5-pin Euroblock 1 x 5-pin Euroblock
Impedance — — 0 dBV, 600 Ω, balanced 0 dBV, 600 Ω, balanced
Direct out 1 – 8 — 8 x 5-pin Euroblock 8 x 5-pin Euroblock 8 x 5-pin Euroblock
Impedance — 0 dBV, 600 Ω, unbalanced 0 dBV, 600 Ω, unbalanced 0 dBV, 600 Ω, unbalanced
Z2 / MOH output — 1 x 5-pin Euroblock 1 x 5-pin Euroblock 1 x 5-pin Euroblock
Impedance —
Z2: +4 dBV, 600 Ω, balanced
MOH: 0 dBV, 600 Ω, balanced
0 dBV, 600 Ω, balanced 0 dBV, 600 Ω, balanced
Amplier
Amplier channels
LO-Z: 1 x 4 Ω, minimum
HI-Z: 1 x 70 / 100 V, switchable
—
LO-Z: 1 x 4 Ω, minimum
HI-Z: 1 x 70 / 100 V, switchable
LO-Z: 1 x 4 Ω, minimum
HI-Z: 1 x 70 / 100 V, switchable
Power output LO-Z
1% THD, 1 kHz sinewave
130 W RMS @ 8 Ω
240 W RMS @ 4 Ω
—
100 W RMS @ 8 Ω
180 W RMS @ 4 Ω
80 W RMS @ 8 Ω
120 W RMS @ 4 Ω
Min. impedance 4 Ω — 4 Ω 4 Ω
Power output HI-Z
1% THD, 1 kHz sinewave
240 W RMS @ 70 V
240 W RMS @ 100 V
—
180 W RMS @ 70 V
180 W RMS @ 100 V
80 W RMS @ 70 V
80 W RMS @ 100 V
Min. impedance
20 Ω @ 70 V
42 Ω @ 100 V
—
27 Ω @ 70 V
55 Ω @ 100 V
62 Ω @ 70 V
125 Ω @ 100 V
MA6480A MA6000M MA6018 MA6008
System Information
Dynamic range
Mic: 65 dB
Line: 80 dB
THD + N 0.5% @ 1 kHz, rated output
Frequency response 50 Hz - 18 kHz, +/- 2 dB
Tone controls
Low: +/- 15 dB at 20
Hz - 800Hz, Mid: +/- 15
dB at 700Hz - 7 kHz, High:
+/- 15dB at 5 kHz - 20 kHz,
Q: 0.5 to 5
Master: Low: +/- 10 dB @ 100 Hz
High: +/- 10 dB @ 12 kHz
Input 1-8: Low: +/- 15 dB @ 100 Hz
High: +/- 15 dB @ 12 kHz
Aux: Low: +/- 10 dB @ 100 Hz
High: +/- 10 dB @ 12 kHz
Control Connections
Remote 1 x 5-pin Euroblock connector
Common -5 VDC, 100 mA current, short-circuit protected
Remote power +5 VDC, 100 mA current limited, short-circuit protected
RVC 10 kΩ linear-taper potentiometer
Aux input select —
Used in conjunction with
wall remote to select aux
input feeding main mix
Used in conjunction with
wall remote to select aux
input feeding main mix
Used in conjunction with
wall remote to select aux
input feeding main mix
Unit power on/o +5 VDC voltage make contact input, no open voltage
Mute
No-voltage make contact
input; open voltage 5 VDC
Short circuit: < 10 mA
— — —
Tel / Page —
1 x 5-pin Euroblock,
1terminal
1 x 5-pin Euroblock,
1terminal
1 x 5-pin Euroblock,
1terminal
Control —
No-voltage make contact
input; open voltage 5 VDC
Short circuit: < 10 mA
No-voltage make contact
input; open voltage 5 VDC
Short circuit: < 10 mA
No-voltage make contact
input; open voltage 5 VDC
Short circuit: < 10 mA
Inputs 1-8 Input 1 — — —
Control
No-voltage make contact input; open voltage 5 VDC
Short circuit: < 10 mA
Indicators
Power LED ring illumination (Yellow)
Overload / protection LED ring indication (Red)
Output level LED VU output meter (Yellow and Red while clipping)
Power Supply (Fuses)
Mains voltage
Switchable, 100-120/220-
240 VAC, 50/60 Hz
100-240 VAC 50/60 Hz
Switchable, 100-120/220-
240 VAC, 50/60 Hz
Switchable, 100-120/220-
240 VAC, 50/60 Hz
Fuse T 6.3 AH 250 V / T 3.15 AH 250V T 1 AH 250 V T 6.3 AH 250 V / T 3.15 AH 250V T 5 AH 250 V / T 2.5 AH 250V
Power eciency 77% max. — 72% max. 67% max.
Power consumption
39 W @ idle
120 W @ 1/8 power
240 W @ 1/3 power
620 W @ full power
—
54 W @ idle
110 W @ 1/8 power
210 W @ 1/3 power
500 W @ full power
44 W @ idle
70 W @ 1/8 power
110 W @ 1/3 power
240 W @ full power
Mains connector Standard IEC receptacle
Dimensions / Weight
Dimensions (H x W x D)
3.5 x 17 x 16"
88 x 432 x 406 mm
Weight 12.8 lbs / 5.8 kg 11.0 lbs / 5 kg 14.1 lbs / 6.4 kg 13.7 lbs / 6.2 kg
