Global Control Section
MIDI
Ch.
SNAPSHOTS - whole mixer 16
FX 1 / FX 2 - common ctrl. "
[MIDI-Ch. 13 = not used]
Section
MIDI
Ch.
Command
Min.
Value
Max.
Value
Parameter Min. Value Max. Value Notes Comment
Input Ch. 1 1 CC 7 0, 1 127
Channel LEVEL
(to MAIN)
OFF, -70 dB +10 dB
Value 0 = OFF, Value 1~127
= the actual level control
from -70 to +10 dB
" " CC 10 0 127
Channel BALANCE
(to MAIN)
1.0 LEFT 1.0 RIGHT Value 64 = "0.0 CENTER"
" " CC 5 0 1-127 MUTE NO MUTE MUTE
Switch; value 0 = "MUTE
OFF"; value 1-127 = "MUTE"
" " CC 6 0 1-127 SOLO NO SOLO SOLO
Switch; value 0 = "SOLO
OFF"; value 1-127 = "SOLO"
" " CC 1 0 127 EQ LOW -15 dB +15 dB
Continuous control; value
64 = "0.0 dB" (center
postion)
" " CC 2 " " EQ LOW MID " " "
" " CC 3 " " EQ HI MID " " "
" " CC 4 " " EQ HI " " "
" " CC 8 0 127 GAIN -20 dB +60 dB NOT on Ch. USB/BT Continuous control
" " CC 9 0 127 LOW CUT 20 Hz 600 Hz NOT on Ch. USB/BT Continuous control
" " CC 11 0 100-127 COMP 0% 100% NOT on Ch. USB/BT
Continuous control; values
101-127 = identical to max.
value = 100%
" " CC 12 0 1-127 48 V OFF ON ONLY on Ch. 1 + 2
Switch; value 0 = "48V
OFF"; value 1-127 =
"48V ON"
" " CC 14 0, 1 127
SEND LEVEL to
MON1
OFF, -70 dB +10 dB
Value 0 = OFF, Value 1~127
= the actual level control
from -70 to +10 dB
" " CC 15 0, 1 127
SEND LEVEL to
MON2
OFF, -70 dB +10 dB "
" " CC 16 0, 1 127 SEND LEVEL to FX 1 OFF, -70 dB +10 dB "
" " CC 17 0, 1 127 SEND LEVEL to FX 2 OFF, -70 dB +10 dB "
Section
MIDI
Ch.
Command
Min.
Value
Max.
Value
Parameter Min. Value Max. Value Notes Comment
MAIN BUS 8 CC 7 0, 1 127 BUS LEVEL OFF, -70 dB +10 dB
Value 0 = OFF, Value 1~127
= the actual level control
from -70 to +10 dB
" " CC 10 0 127 BUS BALANCE 1.0 LEFT 1.0 RIGHT ONLY on MAIN BUS Value 64 = "0.0 CENTER"
" " CC 8 0 127 BUS LIMITER -30 dB 0 dB NOT on FX 1/2 BUS Continuous control
" " CC 11 0 127 9-BAND EQ 62 Hz -15 dB +15 dB NOT on FX 1/2 BUS
Continuous control; value
64 = "0.0 dB"
(center postion)
" " CC 12 " " 9-BAND EQ 125 Hz " " " "
" " CC 13 " " 9-BAND EQ 250 Hz " " " "
" " CC 14 " " 9-BAND EQ 500 Hz " " " "
" " CC 15 " " 9-BAND EQ 1 kHz " " " "
" " CC 16 " " 9-BAND EQ 2 kHz " " " "
" " CC 17 " " 9-BAND EQ 4 kHz " " " "
" " CC 18 " " 9-BAND EQ 8 kHz " " " "
" " CC 19 " " 9-BAND EQ 16 kHz " " " "
Section
MIDI
Ch.
Command
Min.
Value
Max.
Value
Parameter Min. Value Max. Value Notes Comment
FX 1 / FX 2 14 / 15 Prog. Chg. 1 16 EFFECT PRESET 1 16
Program Change 0 &
17-127 = ignored
" " CC 1 0 100-127 PARAMETER 1 0% 100%
Continuous control; values
101-127 = identical to
max. value = 100%
" " CC 2 0 1-127 PARAMETER 2 Value A Value B
Switch; MIDI value 0 = "Value A";
MIDI value 1-127 = "Value B"
Section
MIDI
Ch.
Command
Min.
Value
Max.
Value
Parameter Min. Value Max. Value Notes Comment
SNAPSHOT 16 Prog. Chg. 1 16
Load MIXER
SNAPSHOT
1 16 Loading #16 = RESET!
Program Change 0 & 17-127
= ignored; Presets = 1-15;
RESET = Prog. Chg. #16
FX 1 / FX 2 " CC 1 0 1-127 FX MUTE NO MUTE MUTE Mutes BOTH FX Sends
Switch; value 0 = "MUTE
OFF"; value 1-127 = "MUTE"
FX 1 / FX 2 " Note 0 (C -1) Velocity 1 Velo. 127 TAP TEMPO 50 BPM 250 BPM See below!
Lowest MIDI note for tempo
tapping; ignore Velocity 0,
any velo. btw. 1-127 = OK
OVERVIEW
INPUT CHANNELS
BUSSES
FX CONTROL
GLOBAL CONTROL
>Each Input Channel is assigned to one specific MIDI-Channel.
>Each BUS is assigned to one specific MIDI-Channel.
>Each FX slot is assigned to one specific MIDI-Channel.
> ALL global controls operate on MIDI-Channel 16. Notes to TAP TEMPO:
1.) Note On command will be used to control the FX tempo; Note Off will be ignored.
2.) Any Note Velocity from 1-127 is OK for triggering, Velocity 0 will be ignored.
3.) Tempo calculation will be done by measuring the time interval between repetitive hit of MIDI-Note 0
(same logic as for the hardware TAP button on the mixer).
4.) TAP TEMPO affects generally both FX slots, so it's a "global tempo".
5.) TAP TEMPO is only useable for delay/echo effects which offer this parameter ( FX 2 > Presets No. 1-12).
MIDI Implementation
Input Channels
Section
MIDI
Ch.
Input Ch. 1 1
Input Ch. 2 2
Input Ch. 3 3
Input Ch. 4 4
Input Ch. 5/6 5
Input Ch. 7/8 6
Input Ch. USB/BT 7
Busses
Section
MIDI
Ch.
MAIN BUS 8
MON1 BUS 9
MON2 BUS 10
FX 1 BUS 11
FX 2 BUS 12
FX-Slots
Section
MIDI
Ch.
FX 1 14
FX 2 15
